LED EX Light 120 cm 100W 5000K – ATEX Zone 1/2/21/22 – Delivery 14 Business Days

Why choose the LED EX Light 100W

Explosion-proof lighting carries real compliance obligations, and this fitting meets them without compromise. ATEX certification covers both gas and dust hazardous zones, the IP66 enclosure handles wash-downs and heavy contamination, and the wide 100–277V input means it integrates into virtually any industrial electrical installation across the EU. At €291.45 it delivers certified safety at a fraction of the cost of branded alternatives.

• Efficiency: At 110 lm/W, this 100W fitting replaces a 400W conventional tube, cutting energy consumption by 75% without reducing working light levels.
• Safety certification: Full ATEX approval for Zone 1, 2, 21 and 22 means it is legally compliant for use in atmospheres with flammable gases, vapours and combustible dusts.
• Build quality: The pure aluminium housing dissipates heat effectively, supports the 100,000-hour rated lifespan, and withstands operating temperatures from -25 to 45°C.
• Driver protection: The integrated driver includes over-current, over-temperature, over-voltage and short-circuit protection, reducing the risk of failure in demanding industrial conditions.

Where to use it

This fitting is specified for locations where explosive atmospheres may be present: petrochemical plants, fuel storage facilities, paint spray booths, grain silos, flour mills, chemical processing areas and offshore installations. At 100W and 11,100 lm it suits mounting heights of 4–8 metres, providing adequate illuminance for walkways, production lines and inspection areas in Zone 1, 2, 21 and 22 classified spaces.

What the specifications mean in practice

• 110 lm/W: Every watt produces 110 lumens of usable light, so running costs are roughly a quarter of the 400W fitting this replaces — a significant saving in facilities that operate around the clock.
• IP66: The enclosure is fully dust-tight and protected against powerful water jets, making it suitable for wash-down areas and outdoor-exposed industrial structures.
• 5000K: A cool daylight colour temperature improves contrast and visual acuity in task-critical environments such as inspection lines, chemical handling areas and machinery bays.
• 100,000 hours: At 16 hours of daily operation, this equates to over 17 years before the light source reaches end of rated life, minimising maintenance access in restricted hazardous zones.
• ATEX Zone 1/2/21/22: Certification covers both gas/vapour zones (1 and 2) and combustible dust zones (21 and 22), giving a single fitting that satisfies the broadest range of hazardous area classifications.

Installation and compatibility

The fitting accepts 100–277V AC, eliminating voltage compatibility concerns across EU sites. The integrated driver requires no external gear. Surface or suspended mounting options apply depending on the housing bracket selected. Dimming is not specified for this variant. Clightstore provides a free DIALux light study to confirm the number of fittings and spacing required for your classified zone.
